4.4110Surface-Spotlight

For illumination of wide and high fountains.

Description

  • Protection class IP68 – up to 3m water depth
  • Entirely made of stainless steel 316Ti 1.4571
  • Mounting bracket adjustable through 180°
  • Metal halogen vapour lamps
  • with a symmetrical stainless steel reflector
  • Cable gland PG16/21, marine grade 316Ti stainless steel
  • Temperature-resistant silicon seal
  • Toughened safety glass
  • Ballast and Ignitor fitted depending on type, without light source

Notes/Options

  • Coloured HIT light sources available
  • POW-LED on request

Accessories / Housings

4.0004.40.16

  • double cable gland
  • made of V4A-stainless steel

4.0008.01.00

  • anti-glare louver

4.0085.01.00

  • glass disc, frosted
  • for softer light distribution (light loss approx. -15%)
Article number Lamps Lumen Light colour Wattage Current/Voltage Socket Radation angle Cable
Versions: Under- and overwater operations (According to prior agreement)
Flood
4.4110.00.25 HIE 17000 5200K 250W E40 80° Si, 3x2,5 qmm
4.4110.00.26 HSE-MF 31.000lm 2000K 250W E40 80° Si, 3x2,5 qmm
Spot
4.4110.00.29 HIT-DE 22000 3200K 250W Fc2 16° Si, 3x2,5 qmm
4.4110.00.30 HST-DE 25.500lm 2000K 250W Fc2 20° Si, 3x2,5 qmm
Versions: Underwater environments only
Flood
4.4110.00.40 HSE-MF 54.000lm 2000K 400W E40 80° Si, 3x2,5 qmm
4.4110.00.41 HIE 28000 5800K 400W E40 80° Si, 3x2,5 qmm
Spot
4.4110.00.43 HIT-DE 36000 4200K 400W Fc2 35° Si, 3x2,5 qmm
4.4110.00.44 HST-DE 48.000lm 2000K 400W Fc2 35° Si, 3x2,5 qmm
